Vintage Schwinn Conversion Headset Use A 1 1/8” Fork With 1” Head

                            Note all colors are in stock NOW

                                  Buy now for Christmas!

                                         FREE SHIPPING!

 Old School Schwinn and BMX Conversion Headset, Use Your 1 1/8” Fork With 1” Head tube Frame. This will also fit old school BMX frames but please measure to confirm the 32.7mm inside diameter head tube. For threadless forks, and  external cup frames.

Newest generation! These headsets have the best finish and a new extra rubber

seal in the upper cover to keep out the elements.

                                                  Color is Black.

 This is a conversion headset for vintage Schwinn frames and BMX frames made from 1950 to 1980. It is machined to fit what is known as a 1” steer tube, actual machined diameter of the headset is 32.7 mm, or 1.287”. This will allow a normal press fit, and matches the original size Schwinn steel cup dimensions. Stack height is 31mm. These are made from lightweight aluminum alloy.

 This is a modern sealed bearing headset. The bearings are a standard size  and everything is here, including the crown race, star nut, and top cap.

Use of this item requires some experience and technical skills. These headsets should be installed by an experienced bicycle mechanic.

 This will not fit modern road bikes, which use a smaller 30.2mm size, Please measure first.

 Installation requires a headset press.  There are no returns for parts which have been installed.

 I will try to answer all questions. Please ask questions before buying, thanks!

 See my other auctions for more colors; Silver, Red, Gold, Blue, some other colors coming soon! Scroll down below and click on "Sellers other items"

 I use all recycled/rescued boxes and packing materials. Everything is packed and wrapped carefully so you will receive your order in excellent condition. Save me in your list of favorite sellers, you never know what I will list next!
